Profile Grinding Services in Penang, Malaysia
K-TOOL Engineering delivers micron-level profile grinding for precision tooling — punches, dies, form tools and gauges machined to exacting tolerances. Trusted by semiconductor, mould & die and automotive manufacturers across Penang, Malaysia and worldwide.
Overview
What is profile grinding?
Profile grinding is a precision machining process that uses a shaped grinding wheel to cut complex two-dimensional profiles into hardened materials. It achieves micron-level accuracy and fine surface finishes on intricate geometries that other methods struggle to hold — sharp internal corners, tight radii and steep angles.
It is the right choice when CNC machining or wire cutting cannot deliver the precision or finish your part demands. For high-tolerance punches and dies, form tools and gauges made from hardened steel or tungsten carbide, profile grinding produces repeatable, production-ready accuracy you can rely on, batch after batch.
Capabilities
Profile grinding capabilities & specifications
Specifications achieved on our profile grinding machines. Every job is reviewed against your drawing and tolerance stack before we quote.
Tolerances
Programmed to a 0.0001 mm (0.1 μm) setting resolution and verified to ±1 μm on our CCD measuring system.
Part types
Punches, dies, form tools, gauges, inserts and profile templates.
Materials
Hardened tool steel, stainless, tungsten carbide and exotic alloys.
Surface finish
Fine, repeatable ground finishes — high surface quality verified under ×50 optical projection.
Part-size range
Work table 600 × 180 mm with grinding travel up to 300 mm (U) × 150 mm (W).
Grinding wheels
Φ60–Φ180 mm wheels at spindle speeds up to 20,000 min⁻¹ for fine detail and form work.
Industries
Industries we serve
Semiconductor & electronics
Production punches and dies, lead frames, bonding tools, test sockets and precision jigs for chip makers and electronics-component manufacturers worldwide — the heart of what we do.
Mould & die
Inserts, ejector components and die details for plastic and metal forming.
Automotive
Stamping punches, dies and gauges for high-volume component lines.
Medical
Micro tooling and surgical-grade components with full traceability.
Related
Explore more of K-TOOL
What tolerances can your profile grinding achieve?
Profiles are programmed to a 0.0001 mm (0.1 μm) setting resolution and verified to ±1 μm on our CCD measuring system — micron accuracy you can rely on, batch after batch.
Which materials can you profile grind?
Hardened tool steels, stainless, tungsten carbide and exotic alloys — the hard materials used for production punches, dies and tooling.
What is your typical lead time?
Lead time depends on complexity and volume, but we return quotes within 24 hours and offer responsive turnaround on both prototype and production tooling.
Do you make tooling for semiconductor manufacturers?
Yes. Semiconductor and electronics tooling is a core specialism — lead frames, bonding tools, test sockets and precision jigs for chip makers across Penang and beyond.
Is there a minimum order quantity?
No. We handle everything from one-off prototypes and single replacement tools to repeatable production batches.
How do I get a quote for profile grinding?
Send your drawing or part specification through our quote request page and our engineering team will respond within 24 hours.
